| Specification | Details |
|---|
| Image Sensor | 1/2.7" |
| Effective Pixels | 1920 (H) × 1080 (V) |
| Minimum Illumination | 0.001 lux@F1.4 (Color, 30 IRE), 0.001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on) |
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| White Balance | Auto, Natural, Street lamp, Outdoor, Manual, Regional custom |
| ROM | 128 MB |
| Gain Control (AGC) | Auto/Manual |
| Lens Type | Fixed-focal |
| Max. Aperture | F1.4 |
| Lens Mount | M12 |
| Close Focus Distance | 1.1 m |
| Day/Night | Auto(ICR)/Color/B/W |
| DORI Distance (3.6mm lens) | Detect: 53.8 m, Observe: 21.5 m, Recognize: 10.8 m, Identify: 5.4 m |
| Back Light Compensation | BLC / HLC / DWDR |
| IR Control | Auto, Manual |
| IR Number | 1 IR LED, 1 Warm light |
| IR Range | 30 meters |
| Warm Light Range | 30 meters |
| Video Compression | Instastream, H.265, H.264, H.264H, H.264B, MJPEG (sub stream only) |
| Stream Capability | Triple stream |
| Frame Rate | Main stream: 2MP (1920×1080) @ 1–25/30 fps
Sub stream 1: 720P (1280×720), D1 (704×576) @ 1–25 fps / (704×480) @ 1–30 fps, VGA (640×480) @ 1–30 fps, CIF (352×240) @ 1–30 fps / (352×288) @ 1–25 fps
Sub stream 2: D1 (704×576) @ 1–25 fps / (704×480) @ 1–30 fps, VGA (640×480) @ 1–30 fps, CIF (352×240) @ 1–30 fps / (352×288) @ 1–25 fps |
| Angle of View | 3.6 mm: H: 86°, V: 46°, D: 103° |
| Smart Search | Works with Smart NVR for intelligent search, event extraction and merging to event videos |
| Resolution | 2MP (1920×1080), 1.3MP (1280×960),
720p (1280×720), D1 (704×576 / 704×480),
VGA (640×480), CIF (352×288 / 352×240) |
| Noise Reduction | 3D NR |
| Privacy Mask | 4 areas |
| Built-in Speaker | Support |
| Image Rotation | 0° / 90° / 180° / 270° (90°/270° supported at 2MP resolution and lower) |
| Video Format | PAL/NTSC |
| Audio Compression | G.711a, G.711Mu, PCM |
| Protocol | SFTP, IPv6, IPv4, DNS, RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS 1.2,
TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS,
ONVIF (Profile S, G, T), unicast, multicast |
| OSD | Camera title, Date & Time |
| Ethernet | RJ-45 (10/100 Base-T) |
| Iris Control | Fixed |
| Mirror Function | Support |
| Bit Rate Control | CBR / VBR |
| Bit Rate | H.265: 3 kbps–6144 kbps, H.264: 8 kbps–6144 kbps |
| Cyber Security | AES 256-bit Encryption, Configuration encryption, Trusted execution,
Digest, Security logs, WSSE, Account lockout, Syslog, Video encryption,
IP/MAC filtering, HTTPS, Trusted upgrade, Trusted boot |
| Browser Support | IE, Chrome, Firefox |
| User/Host | 6 users (Total bandwidth: 36 Mbps) |
| Certificates | ISO 9001:2015, ISO 20000-1:2018, CE, FCC, RoHS, BIS, STQC |
| Power Source | 12 VDC / PoE (802.3af) |
